Home Circuit breakers and residual current protection Circuit breakers Circuit breakers of the E.PRO series Modular circuit breaker 1P 25 A D 6kA, E.NEXT

Modular circuit breaker 1P 25 A D 6kA, E.NEXT

Price excl. tax: €3.85
Price inc. tax: €4.62
  • Code:
    p0710009
The E.NEXT e.mcb.pro.60.1.D.25 modular circuit breaker is designed to protect low-voltage electrical networks and equipment from overload and short circuit, as well as for operational switching of electrical circuits. Thanks to the D characteristic, the circuit breaker is suitable for consumers with high starting currents, including electric motors, transformers, compressors and industrial equipment. It provides reliable protection and safe operation in domestic, commercial and industrial electrical installations.

Estimated Shipping

outside Varna starts at €10.43 to Varna starts at €10.43
to Varna starts at €4.83 outside Varna starts at €5.02
  • Rated current [A]:
    25 A
  • Number of poles:
    1P
  • Shutdown curve:
    D
  • Breaking capacity [kA]:
    6 kA

We have 20 in stock

- +

Quick Buy

Just 4 fields to fill in
We will contact you to finalize the order
Modular circuit breaker 1P 25 A D 6kA, E.NEXT
Modular circuit breaker 1P 25 A D 6kA, E.NEXT Modular circuit breaker 1P 25 A D 6kA, E.NEXT Modular circuit breaker 1P 25 A D 6kA, E.NEXT
Send to friend
Rate this product
Compare
Compliance Information

Technical characteristics

Article: p0710009
Series: e.mcb.pro.60
Product type: modular circuit breaker
Number of poles: 1P
Rated current In: 25 A
Feature: D
Rated operating voltage Ue: AC 230/400 V
Nominal DC voltage per pole: 48 V
Rated frequency: 50 Hz
Breaking capacity Icu: 6 kA
Current limitation class: 3
Impulse withstand voltage Uimp: 6 kV
Insulation voltage Ui: 500 V
Application category: AC-22B
Current type: AC
Degree of protection (IP): IP20
Pollution level: 2
Climate performance: UHL4
Connection to FORK busbar: top and bottom
Max. conductor cross-section: 25 mm²
Terminal tightening torque: 3 Nm
Operating temperature range: -30…+60 °C
Mounting: on DIN rail 35 mm
Operating position: vertical, horizontal, with a deviation of up to 5°
Mechanical/electrical durability: 20,000 / 10,000 cycles
Altitude above sea level: up to 2000 m
Weight: up to 100 g
Compliance with standards: DSTU EN 60898-1, DSTU EN 60947-2
Disposal method: handover to a specialized company
Warranty: 12 months
