Modular circuit breaker 1P 4 A D 6kA, E.NEXT
Price excl. tax:
€2.65
Price inc. tax:
€3.18
-
Code:p0710004
The E.NEXT e.mcb.pro.60.1.D.4 modular circuit breaker is designed to protect low-voltage electrical networks and equipment from overload and short circuit. Characteristic D makes it suitable for circuits with high starting currents, including electric motors, transformers and industrial equipment. The circuit breaker provides reliable protection and allows operational switching in electrical installations.
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical characteristics
Article: p0710004
Product type: modular circuit breaker
Number of poles: 1P
Rated current: 4 A
Feature: D
Rated voltage: AC 230/400 V
Breaking capacity: 6 kA
Current limitation class: 3
Degree of protection (IP): IP20
Mounting: DIN rail 35 mm
Max. conductor cross-section: 25 mm²
Operating temperature range: -30…+60 °C
Compliance with standards: DSTU EN 60898-1, DSTU EN 60947-2
Warranty: 12 months
