Contactor e.pro.ukc, 9 A, 24 V AC, 1 NC, E.NEXT
Price excl. tax:
€8.00
Price inc. tax:
€9.60
-
Code:p009141
The E.NEXT e.pro.ukc contactor is intended for use in stationary electrical installations for remote control - starting, stopping and reversing of three-phase asynchronous electric motors with a squirrel-cage rotor. It is also suitable for switching group lighting circuits and other low-inductive loads. The device ensures reliable operation in industrial conditions and a long service life. The contactor is equipped with an auxiliary contact 1NC and is designed for installation on both a DIN rail and a mounting plate. It is characterized by high mechanical and electrical wear resistance.
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical characteristics
Article: p009141
Number of poles: 3
Rated current (AC-3): 9 A
Application category: AC-3
Rated motor power (AC-3): 4 kW
Rated operating voltage Ue: AC 400/660 V
Insulation voltage Ui: 690 V
Impulse voltage Uimp: 6 kV
Coil voltage: 24 V AC
Rated frequency: 50 Hz
Current type: AC
Additional contacts: 1 NC
Maximum short-term overload: 8 In (t ≤ 1 s)
Degree of protection (IP): IP20
Pollution level: 3
Mounting: DIN rail 35 mm or mounting plate
Operating position: vertical and horizontal (±5°)
Operating temperature range: -25…+50 °C
Maximum altitude: 2000 m
Mechanical wear resistance: ≥10,000,000 cycles
Electrical durability: ≥1,000,000 cycles
Compliance with standards: DSTU EN 60947-4-1
Disposal method: handover to a specialized company
Warranty: 12 months
-
Support contacts:
-
Control voltage Uc [V]:24
