Modular circuit breaker E.INDUSTRIAL.MCB.150.3.D100, 3P, 100 A, curve D, 15kA, E.NEXT
Price excl. tax:
€52.30
Price inc. tax:
€62.76
-
Code:i0630011
The E.INDUSTRIAL.MCB.150 modular circuit breaker is designed to protect low-voltage electrical networks and equipment from overload and short circuit. The device is designed for industrial applications where high breaking capacity and reliable operation are required. The circuit breaker uses a thermomagnetic protection mechanism that provides fast tripping in emergency modes and stable operation during normal operation. Characteristic D allows use in loads with high starting currents such as electric motors, transformers and industrial machines. The device is mounted on a standard 35 mm DIN rail and is suitable for distribution boards, industrial installations and energy systems. It is intended for both protection and non-partial operational switching on and off of electrical circuits.
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical characteristics
Article: i0630011
Product type: Modular circuit breaker
Series: E.INDUSTRIAL.MCB.150
Number of poles: 3P
Rated current In: 100 A
Shutdown characteristic: D
Rated operating voltage Ue: 230/400 V AC
Voltage type: AC
Rated frequency: 50 Hz
Breaking capacity: 15 kA
Protection type: thermal and electromagnetic
Mounting: DIN rail 35 mm
Comb busbar connection: FORK (top and bottom)
Degree of protection (IP): IP20
Operating temperature range: −25…+40 °C
Max. conductor cross-section: up to 50 mm²
Compliance with standards: IEC/EN 60898-1, IEC/EN 60947-2
