Contactor E.INDUSTRIAL, 110 V, 1NO + 1NC, E.NEXT

Technical characteristics

Article: i.0090033
Number of poles: 3P
Impulse withstand voltage Uimp: 8 kV
Utilization category: AC-3
Operating temperature range: -25…+40 °C
Degree of protection (IP): IP20
Type and number of additional contacts: 1NO+1NC
Maximum short-term overload (t≤1 s): 18 In
Altitude above sea level: 2000 m
Insulation voltage Ui: 690 V
Rated operating voltage Ue: AC 400/660 V
Current type: AC
Control coil voltage Uc: 110 V
Rated frequency: 50 Hz
Rated power of the controlled motor AC-3: 22 kW
Pollution degree: 3
Rated operating current (AC-3): 50 A
Mechanical/electrical endurance: 8 000 000 / 800 000 cycles
Mounting: 35 mm DIN rail
Operating position: Any position
Compliance with standards: DSTU EN 60947-1, DSTU EN 60947-4-1
Disposal method: Transfer to a specialized enterprise
Warranty: 12 months
