Contactor UKC 4-80 400 V 1NO+1NC 80 A, 80 A, E.NEXT

Technical characteristics

Article: p009118
Number of poles: 3P
Impulse withstand voltage Uimp: 6 kV
Utilization category: AC-3
Operating temperature range: -25…+50 °C
Degree of protection (IP): IP20
Type and number of additional contacts: 1NO+1NC
Maximum short-term overload (t≤1 s): 8 In
Altitude above sea level: 2000 m
Insulation voltage Ui: 690 V
Rated operating voltage Ue: AC 400/660 V
Current type: AC
Control coil voltage Uc: 400 V
Rated frequency: 50 Hz
Rated power of the controlled motor AC-3: 37 kW
Pollution degree: 3
Rated operating current (AC-3): 80 A
Mechanical/electrical endurance: 6 000 000 / 600 000 cycles
Mounting: 35 mm DIN rail or mounting panel
Operating position: Vertical and horizontal, with deviation not more than 5°
Compliance with standards: DSTU EN 60947-4-1
Disposal method: Transfer to a specialized enterprise
Warranty: 12 months
