Contactor e.pro.ukc.1.18.230.1ns, 1NC, E.NEXT

Technical characteristics

Article: p009123
Number of poles: 3
Impulse withstand voltage Uimp: 6 kV
Application category: AC-3
Type and number of additional contacts: 1NC
Maximum short-term overload (t≤1s): 8 In
Altitude above sea level: 2000 m
Insulation voltage (Ui): 690 V
Rated operating voltage Ue: AC 400/660 V
Current type: AC
Control coil voltage (Uc): 230 V
Rated frequency: 50 Hz
Rated power of the controlled motor (AC-3): 7.5 kW
Pollution degree: 3
Rated operating current (In, AC-3): 18 A
Degree of protection (IP): IP20
Compliance with standards: DSTU EN 60947-4-1
Method of disposal: transfer to a specialized company
Wear resistance mech./el.: <10,000,000 / 1,000,000 cycles
Operating temperature range: -25…+50 °C
Mounting: on 35 mm DIN rail or mounting panel
Operating position: vertical and horizontal, with deviation ≤5°
Warranty: 12 months
