Contactor e.pro.ukc.4.95.230.1NO, 230 V, 1NO+1NC, E.NEXT

Technical characteristics

Article: p009119
Number of poles: 3
Impulse withstand voltage Uimp: 6 kV
Application category: AC-3
Type and number of additional contacts: 1NO+1NC
Max. short-term overload (t≤1s): 8 In
Altitude above sea level: 2000 m
Insulation voltage Ui: 690 V
Rated operating voltage Ue: AC 400/660 V
Current type: AC
Control coil voltage Uc: 230 V
Rated frequency: 50 Hz
Rated. AC-3 controlled motor power: 45 kW
Pollution degree: 3
Rated operating current In (AC-3): 95 A
Degree of protection (IP): IP20
Compliance with standards: DSTU EN 60947-4-1
Disposal method: transfer to a specialized company
Wear resistance mech./el.: < 6 000 000 / 600 000 cycles
Operating temperature range: -25…+50 °C
Mounting: on DIN-rail 35 mm or mounting panel
Operating position: vertical or horizontal, with deviation ≤5°
Warranty: 12 months
