Circuit breaker e.industrial.ukm.60S.25, 3p, 25 A, E.NEXT
-
Code:i0010026
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Technical characteristics
Article: i0010026
Number of poles: 3
Weight: 0.75 kg
Impulse withstand voltage Uimp: 6 kV
Insulation voltage Ui: 600 V
Application category: A
Terminal tightening torque: 10.5 Nm
Rated operating voltage Ue: AC 600 V
Current type: AC
Rated frequency: 50 Hz
Short-circuit tripping setting Im: 10 In ±20 %
Max. conductor cross-section: 12.5×3 mm²
Degree of protection (IP): housing – IP30, terminals – IP00
Compliance with standards: DSTU EN 60947-1, EN 60947-2
Disposal method: handover to a specialized company
Nom. limit breaking capacity Icu: 10 kA
Rated current In: 25 A
Wear resistance mech./el.: < 8500/6000 cycles
Rated operating breaking capacity Ics (AC 400 V): 5 kA
Operating temperature range: -25…+40 °C
Mounting: on mounting panel
Altitude above sea level: ≤2000 m
Characteristics: magnetic-hydraulic distributor
Operating position: vertical or horizontal, with deviation ≤5°
Warranty: 12 months
