Contactor e.industrial.ukc.65.24, 1 NO + 1 NC, E.NEXT

Technical characteristics

Article: i.0090036
Number of poles: 3
Impulse withstand voltage Uimp: 8 kV
Application category: AC-3
Additional contacts: 1 NO + 1 NC
Max. short-term overload (t ≤ 1 s): 18 In
Altitude above sea level: Up to 2000 m
Insulation voltage (Ui): 690 V
Rated operating voltage Ue: AC 400/660 V
Current type: AC
Control coil voltage (Uc): 24 V
Rated frequency: 50 Hz
Rated power of controlled motor (AC-3): 30 kW
Pollution degree: 3
Rated operating current (AC-3): 65 A
Degree of protection (IP): IP20
Compliance with standards: DSTU EN 60947-1, EN 60947-4-1
Disposal method: Handover to a specialized company
Wear resistance (mechan./el.): ≥ 8,000,000 / 800,000 cycles W/O
Operating temperature range: –25…+40 °C
Mounting: On DIN rail 35 mm
Operating position: Any
Warranty: 12 months
