EARTHQUAKE PROTECTION WITH OVERCURRENT PROTECTION E.INDUSTRIAL.ELCB.2.C25.30, 2P, 25A, C, 30MA E.NEXT
Price excl. tax:
€24.54
48.00лв.
Price inc. tax:
€29.45
57.60лв.
-
Code:i0230005
Estimated Shipping
outside Varna starts at
€3.88
to Varna starts at
€3.88
to Varna starts at
€2.74
outside Varna starts at
€2.85
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: i0230005
Connection to FORK type busbar: no
Current limitation class: 3
Differential tripping current: 30 mA
Number of poles: 1P+N
Current-time characteristic: C
Impulse withstand voltage Uimp: 4 kV
Terminal torque: 3 Nm
Altitude above sea level: 2000 m
Insulation voltage Ui: 500 V
Rated operating voltage Ue: AC 230 V
Current type: AC
Rated frequency: 50 Hz
Max. cross-section of the connected wires: 25 mm²
Protection degree: IP20
Compliance with standards: DSTU EN 61009-1
Disposal method: transfer to a specialized company
Rated breaking capacity Icu: 10 kA
Rated current In: 25 A
Durability mech./el.: ≤10 000 / ≤4 000 cycles
Operating temperature range: –25…+40 °C
Rated making/breaking capacity: 500 A
Mounting: on DIN-rail 35 mm
Characteristics: electromechanical
Operating position: vertical/horizontal (deviation ≤5°)
Weight: ≤180 g
Type: AC
Warranty: 12 months
