Earthquake protection WITH overcurrent protection E.INDUSTRIAL.ELCB.2.C16.30, 2P, 16 A, C, 30 mA, E.NEXT
-
Code:i0230003
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Technical characteristics
Article: i0230003
Connection to FORK type busbar: no
Current limitation class: 3
Differential tripping current: 30 mA
Number of poles: 1P+N
Current-time characteristic: C
Impulse withstand voltage Uimp: 4 kV
Terminal tightening torque: 3 Nm
Altitude above sea level: 2000 m
Insulation voltage Ui: 500 V
Rated operating voltage Ue: AC 230 V
Current type: AC
Rated frequency: 50 Hz
Max. cross-section of the connected wires: 25 mm²
Degree of protection (IP): IP20
Compliance with standards: DSTU EN 61009-1
Disposal method: transfer to a specialized company
Nominal breaking capacity Icu: 10 kA
Rated current In: 16 A
Durability mech./el.: ≤10 000 / ≤4 000 cycles
Operating temperature range: –25…+40 °C
Nominal making/breaking capacity: 500 A
Mounting: on DIN-rail 35 mm
Characteristics: electromechanical
Operating position: vertical/horizontal (deviation ≤5°)
Weight: ≤180 g
Type: AC
Warranty: 12 months
