Residual current circuit breaker (RCCB) E.RCCB.PRO.2.40.300, 2, 40 A, 300 mA, type AC, E.NEXT

Price excl. tax: €20.04
Price inc. tax: €24.05
  • Code:
    p003014
Residual current circuit breaker (RCCB) E.RCCB.PRO.2.40.300, 2, 40 A, 300 mA, type AC. Key characteristics: busbar type: without FORK (fork); impulse withstand voltage Uimp: 6 kV; terminal tightening torque: 3.5 Nm.

Estimated Shipping

outside Varna starts at €10.43 to Varna starts at €10.43
to Varna starts at €4.83 outside Varna starts at €5.02
  • Rated current [A]:
    40 A
  • Number of poles:
    2P
  • Shutdown curve:
  • Maximum leakage current [mA]:
    300 mA
  • Type:
  • Short circuit and overload protection:

We have 30 in stock

- +

Quick Buy

Just 4 fields to fill in
We will contact you to finalize the order
Residual current circuit breaker (RCCB) E.RCCB.PRO.2.40.300, 2, 40 A, 300 mA, type AC, E.NEXT
Residual current circuit breaker (RCCB) E.RCCB.PRO.2.40.300, 2, 40 A, 300 mA, type AC, E.NEXT Residual current circuit breaker (RCCB) E.RCCB.PRO.2.40.300, 2, 40 A, 300 mA, type AC, E.NEXT Residual current circuit breaker (RCCB) E.RCCB.PRO.2.40.300, 2, 40 A, 300 mA, type AC, E.NEXT
Send to friend
Rate this product
Compare
Compliance Information

Technical characteristics

Article: p003014
Busbar type: without FORK (fork)
Current limitation class: 2
Differential current: 300 mA
Number of poles: 2
Impulse withstand voltage Uimp: 6 kV
Terminal tightening torque: 3.5 Nm
Altitude above sea level: up to 2000 m
Insulation voltage (Ui): 500 V
Rated operating voltage Ue: AC 230 V
Rated frequency: 50 Hz
Climatic version: UHL4
Max. conductor cross-section: 25 mm²
Degree of protection (IP): IP20
Compliance with standard: DSTU EN 61008-1
Limited breaking capacity (Icu): 6 kA
Rated current In: 40 A
Mechanical/electrical durability: <10,000 / 4,000 cycles
Operating temperature range: -25…+40 °C
Switching current: 1000 A
Mounting: DIN rail 35 mm
Type: AC
Mounting position: vertical/horizontal (deviation ≤ 5°)
Weight: ≤190 g
Warranty: 12 months
