Residual current circuit breaker (RCCB) E.RCCB.PRO.2.80.30, 2P, 80 A, type AC, E.NEXT
-
Code:p003007
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Technical characteristics
Article: p003007
Type: AC
Number of poles: 2P
Rated current In: 80 A
Rated differential current (IΔn): 30 mA
Rated operating voltage Ue: AC 230 V
Rated frequency: 50 Hz
Rated breaking capacity (Icu): 6 kA
Rated making and breaking capacity: 1000 A
Current limitation class: 2
Impulse withstand voltage Uimp: 6 kV
Insulation voltage (Ui): 630 V
Maximum cross-section of connected wires: 25 mm²
Tightening torque of contact terminals: 3.5 Nm
Connection with FORK type comb busbar: No
Mounting: DIN rail 35 mm
Operating position: Vertical or horizontal, with a deviation of up to 5°
Operating temperature range: −25…+40 °C
Maximum altitude: 2000 m
Degree of protection (IP): IP20
Climate performance: UHL4
Mechanical/electrical durability: 10,000/4,000 cycles
Feature: Electromechanical
Weight: ≤ 190 g
Compliance with standards: DSTU EN 61008-1
Disposal method: Handover to a specialized company
Warranty: 12 months
