Magnetic starter E.INDUSTRIAL.UKQ.22MB, 400 V, 22 A, E.NEXT
Price excl. tax:
€29.48
Price inc. tax:
€35.38
-
Code:i0100004
Magnetic starter E.INDUSTRIAL.UKQ.22MB, 400 V, 22 A. Key characteristics: number of poles: 3; range of operating current setting: 16–22 A; impulse withstand voltage Uimp: 6 kV.
Estimated Shipping
outside Varna starts at
€11.49
to Varna starts at
€11.49
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical characteristics
Article: i0100004
Number of poles: 3
Range of operating current setting: 16–22 A
Impulse withstand voltage Uimp: 6 kV
Application category: AC-3
Maximum short-term overload (t ≤ 1 s): 18 In
Altitude above sea level: 2000 m
Insulation voltage Ui: 690 V
Rated operating voltage Ue: AC 230/400 V
Current type: AC
Coil voltage Uc: AC 400 V
Rated frequency: 50 Hz
Pollution degree: 3
Degree of protection (IP): IP55
Compliance with standards: DSTU EN 60947-1; EN 60947-4-1 DSTU
Disposal method: transfer to a specialized company
Rated current In: 22 A
Operating temperature range: −25…+40 °C
Protection class: 0/I
Operating position: vertical/horizontal, deviation up to 30°
Warranty: 12 months
