MCCB E.INDUSTRIAL.UKM.250S.175, E.NEXT
-
Code:i0010013
Estimated Shipping
outside Varna starts at
€11.49
to Varna starts at
€11.49
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Technical characteristics
Article: i0010013
Number of poles: 3
Impulse withstand voltage Uimp: 8 kV
Insulation voltage Ui: 800 V
Utilization category: A
Operating temperature range: -25…+40 °C
Degree of protection (IP): Circuit breaker housing – IP30; terminal side – IP00
Weight: 1,5 kg
Tightening torque: 22,5 Nm
Rated operating voltage Ue: AC 660
Current type: AC
Rated frequency: 50 Hz
Short-circuit trip setting Im: 10 In±20 % A
Max. cross-section of the connected wires: 20*4 mm²
Rated breaking capacity Icu: 50 kA
Rated current In: 175 A
Mechanical/electrical endurance, ON-OFF cycles, min.: 7000/2000
Ics (AC 400 V): 35 kA
Connection: via busbar e.industrial.ukm.250S.busbar (i0050002)
Mounting: On mounting panel
Altitude above sea level, max.: 2000 m
Characteristics: Thermomagnetic protection unit
Operating position: Vertical and horizontal with deviation not more than 5°
Compliance with standards: DSTU EN 60947-1, DSTU EN 60947-2
Disposal method: Transfer to a specialized enterprise
Warranty: 12 months
