MCCB E.INDUSTRIAL.UKM.630S.500, E.NEXT
-
Code:i0010028
Estimated Shipping
outside Varna starts at
€22.50
to Varna starts at
€22.50
to Varna starts at
€14.24
outside Varna starts at
€14.43
Quick Buy
Technical characteristics
Article: i0010028
Number of poles: 3
Impulse withstand voltage Uimp: 8 kV
Insulation voltage Ui: 800 V
Utilization category: A
Operating temperature range: -25…+40 °C
Degree of protection (IP): Circuit breaker housing – IP30; terminal side – IP00
Weight: 10,9 kg
Tightening torque: 22,5 Nm
Rated operating voltage Ue: AC 660
Current type: AC
Rated frequency: 50 Hz
Short-circuit trip setting Im: 10 In±20 % A
Max. cross-section of the connected wires: 40*10 mm²
Rated breaking capacity Icu: 70 kA
Rated current In: 500 A
Mechanical/electrical endurance, ON-OFF cycles, min.: 2500/500
Ics (AC 400 V): 70 kA
Connection: via busbar e.industrial.ukm.630S.busbar (i0050005)
Mounting: On mounting panel
Altitude above sea level, max.: 2000 m
Characteristics: Thermomagnetic protection unit
Operating position: Vertical and horizontal with deviation not more than 5°
Compliance with standards: DSTU EN 60947-1, DSTU EN 60947-2
Disposal method: Transfer to a specialized enterprise
Warranty: 12 months
