ADDITIONAL EMERGENCY CONTACT E.MCB.ALT E.NEXT
Price excl. tax:
€5.60
10.95лв.
Price inc. tax:
€6.72
13.14лв.
-
Code:p042101
Estimated Shipping
outside Varna starts at
€3.88
to Varna starts at
€3.88
to Varna starts at
€2.74
outside Varna starts at
€2.85
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: p042101
Possibility of FORK type busbar: no
Tightening torque of terminals: 2 Nm
Altitude above sea level: 2000 m
Nominal frequency: 50 Hz
Max. conductor cross-section: 2.5 mm²
Protection degree: IP20
Compliance with standards: DSTU EN 60898-1; EN 60947-2 DSTU
Disposal method: handover to a specialized company
Nominal current (AC-12): 3 A (415 V), 6 A (240 V); (DC-12): 1 A (125 V), 2 A (48 V)
Contact: 1 changeover (1 C/O)
Operating temperature: −25…+40 °C
Mounting: on DIN rail 35 mm (left)
Width: 0.5 modules
Operating position: vertical/horizontal, deviation up to 5°
Warranty: 12 months
