MCCB E.INDUSTRIAL.UKM.60S.32, 32 A, E.NEXT
-
Code:i0010001
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Technical characteristics
Article: i0010001
Number of poles: 3
Weight: 0.75 kg
Impulse withstand voltage Uimp: 6 kV
Insulation voltage Ui: 600 V
Application category: A
Terminal tightening torque: 10.5 Nm
Rated operating voltage Ue: AC 600 V
Current type: AC
Rated frequency: 50 Hz
Short-circuit setting Im: 10 In ±20%
Max. connection (busbar): 12.5×3 mm
Degree of protection (IP): housing IP30; terminal side IP00
Compliance with standards: DSTU EN 60947-1; EN 60947-2 DSTU
Disposal method: handover to a specialized company
Rated pre-limit breaking capacity Icu: 10 kA
Rated current In: 32 A
Mechanical/electrical durability: ≤ 8500/6000 cycles
Rated operational breaking capacity Ics (AC 400 V): 5 kA
Operating temperature range: −25…+40 °C
Mounting: on a mounting plate
Altitude above sea level: no more than 2000 m
Characteristics: magnetic-hydraulic disconnector
Operating position: vertical/horizontal, deviation up to 5°
Warranty: 12 months
