POWER circuit breaker E.INDUSTRIAL.UKM.250RE.160 WITH electronic cut-off, 3P, 160 A, E.NEXT
Price excl. tax:
€166.17
Price inc. tax:
€199.40
-
Code:i0770057
POWER circuit breaker E.INDUSTRIAL.UKM.250RE.160 WITH electronic cut-off, 3P, 160 A. Key characteristics: uimp: 8 kV; ui: 1000 V; maximum short-term overload (t ≤ 1 s): 2000 A.
Estimated Shipping
outside Varna starts at
€12.53
to Varna starts at
€12.53
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical characteristics
Article: i0770057
Number of poles: 3
Uimp: 8 kV
Ui: 1000 V
Category: B
Maximum short-term overload (t ≤ 1 s): 2000 A
Tightening torque: 10 Nm
Ue: AC 690 V
Current type: AC
Rated frequency: 50 Hz
Max. conductor cross-section: 50 mm²
IP: housing IP30; terminals IP00
Compliance with standards: DSTU EN 60947-1; EN 60947-2 DSTU
Utilization: specialized enterprise
Icu: 50 kA
In: 100 A
Endurance mech./el.: ≤ 40000/8000 cycles
Ics (AC 400 V): 50 kA
Operating temperature range: −30…+70 °C
Mounting: mounting plate
Disconnector type: electronic
Altitude: ≤ 2000 m
Operating position: vertical/horizontal, up to 5°
Warranty: 24 months
