Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT

Price excl. tax: €1.87 3.66лв.
Price inc. tax: €2.24 4.38лв.
  • Code:
    s001012
The modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, characteristic B, 4.5 kA is designed to protect low-voltage electrical networks and equipment from overload and short circuit, as well as for partial operational switching of electrical circuits.

Estimated Shipping

outside Varna starts at €10.43 to Varna starts at €10.43
to Varna starts at €4.83 outside Varna starts at €5.02
  • Number of poles:
    1P
  • Rated current [A]:
    40 A
  • Shutdown curve:
    B
  • Breaking capacity [kA]:
    3 kA

We have 2952 in stock

- +

Quick Buy

Just 4 fields to fill in
We will contact you to finalize the order
Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT
Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT Modular circuit breaker e.mcb.stand.45.1.B40, 1P, 40 A, B, 4.5 kA E.NEXT
Send to friend
Rate this product
Compare
Compliance Information

Technical characteristics

Item: s001012
Rated current (In): 40 A
Number of poles: 1P
Weather characteristic: B
Rated breaking capacity (Icu): 4.5 kA
Rated operating voltage (Ue): AC 230/400 V
Nominal DC voltage: 48 V/pole
Current type: AC
Nominal frequency: 50 Hz
Current limitation class: 3
Impulse withstand voltage (Uimp): 6 kV
Insulation voltage (Ui): 500 V
Application category: AC-22 B
FORK busbar connection: No
Degree of protection: IP20
Operating temperature: –30…+60 °C
Climate performance: UHL4
Pollution level: 2
Maximum cross-section of connecting wires: 25 mm²
Tightening torque of contact terminals: 3 Nm
Mechanical/electrical durability: ≥10,000 / 4,000 cycles
Mounting: On a 35 mm DIN rail
Operating position: Vertical or horizontal, with a deviation of up to 5°
Maximum altitude above sea level: 2000 m
Mass: ≤100g
Compliance with standards: DSTU EN 60898-1, DSTU EN 60947-2
Disposal method: Handover to a specialized company
Warranty: 12 months
