DOUBLE RECTANGULAR BUTTON E.MB.BL8325, GREEN/RED, NO+NC E.NEXT
Price excl. tax:
€3.58
7.00лв.
Price inc. tax:
€4.29
8.39лв.
-
Code:p0810120
Estimated Shipping
outside Varna starts at
€3.88
to Varna starts at
€3.88
to Varna starts at
€2.74
outside Varna starts at
€2.85
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: p0810120
Insulation resistance: ≥100 MΩ
Diameter: 22 mm
Color: red + green
Supply voltage: AC 400 V, DC 220 V
Altitude above sea level: 2000 m
Insulation voltage (Ui): 600 V
Current type: AC/DC
Nominal frequency: 50 Hz
Environmental pollution degree: 3
Protection degree: IP40
Compliance with standards: DSTU EN 60947-1; EN 60947-5-1
Disposal method: handover to a specialized company
Actuating element: non-fixed
Durability mech./el.: not less than 100×10⁴ / 500×10⁴ cycles
Contact: 1NO + 1NC
Operating temperature range: −25…+55 °C
Mounting: panel
Features: without backlight
Operating position: arbitrary
Rated operating current (In) for AC-15, 220/380 V: 10/6 A
Warranty: 12 months
