THERMAL PROTECTION RELAY E.INDUSTRIAL.UKH.22.22, NOMIN. TOK 22A, DIAP. ON SET 16-22 A E.NEXT
Price excl. tax:
€7.75
15.16лв.
Price inc. tax:
€9.30
18.19лв.
-
Code:i0110008
Estimated Shipping
outside Varna starts at
€3.88
to Varna starts at
€3.88
to Varna starts at
€2.74
outside Varna starts at
€2.85
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: i0110008
Number of poles: 3
Size (max. current for this size): 22 A
Range of operating current setting: 16–22 A
Impulse withstand voltage Uimp: 6 kV
Type and number of additional contacts: 1NO+1NC
Tightening torque of terminals: 2.5 Nm
Altitude above sea level: 2000 m
Weight (not more than): 0.11 kg
Insulation voltage Ui: 690 V
Rated operating voltage Ue: AC 400/660 V
Current type: AC
Rated frequency: 50 Hz
Environment pollution degree: 3
Max. cross-section of connected wires: 6 mm²
Protection degree: IP20
Compliance with standards: DSTU EN 60947-1; EN 60947-4-1
Disposal method: handover to a specialized company
Operating temperature range: -25…+40 °C
Operating position: vertical and horizontal, with a deviation of no more than 30°
Warranty: 12 months
