Residual current protection with overcurrent protection e.elcb.stand.2.C10.30, 1P+N, 10A, C, 30mA, 4.5kA, type AC, split handle, E.NEXT
Price excl. tax:
€40.00
78.23лв.
Price inc. tax:
€48.00
93.88лв.
-
Code:p0620005
The residual current device e.elcb.stand.2.C10.30 is designed to protect electrical circuits and people from earth leakage currents, as well as for overload and short circuit protection.
The device has a rated current of 10 A, time characteristic C, rated differential current 30 mA and breaking capacity 4.5 kA. The design is 1P+N, type AC, with electronic operating principle and mounting on a 35 mm DIN rail
Estimated Shipping
outside Varna starts at
€10.43
to Varna starts at
€10.43
to Varna starts at
€4.83
outside Varna starts at
€5.02
Quick Buy
Just 4 fields to fill in
Technical characteristics
Rated current: 10 A
Number of poles: 1P+N
Feature: C
Differential tripping current: 30 mA
Type: AC
Rated operating voltage: AC 230 V
Nominal frequency: 50 Hz
Breaking capacity: 4.5 kA
Impulse withstand voltage Uimp: 4 kV
Insulation voltage Ui: 400 V
Maximum conductor cross-section: 25 mm²
Current limitation class: 3
Mounting: DIN rail 35 mm
Degree of protection: IP20
Operating temperature: -25°C to +40°C
Execution type: electronic
Mechanical/electrical durability: 10,000 / 4,000 cycles
Rated switching capacity: 500 A
Mounting position: vertical or horizontal
Weight: 180g
Standard: DSTU EN 61009-1
Warranty: 12 months
