FAULT CURRENT PROTECTION DTZ E.RCCB.STAND.2.16.10 2P, 16A, 10MA E.NEXT
Price excl. tax:
€12.76
24.96лв.
Price inc. tax:
€15.31
29.94лв.
-
Code:s034006
Estimated Shipping
outside Varna starts at
€3.88
to Varna starts at
€3.88
to Varna starts at
€2.74
outside Varna starts at
€2.85
Quick Buy
Just 4 fields to fill in
Technical specifications
Article: s034006
Connection to FORK type busbar: no
Current limitation class: 2
Differential tripping current: 10 mA
Number of poles: 2
Impulse withstand voltage Uimp: 6 kV
Terminal torque: 3.5 Nm
Altitude above sea level: 2000 m
Insulation voltage Ui: 500 V
Rated operating voltage Ue: AC 230 V
Rated frequency: 50 Hz
Climatic performance: UHL4
Max. cross-section of the connected wires: 25 mm²
Protection degree: IP20
Compliance with standards: DSTU EN 61008-1
Disposal method: transfer to a specialized company
Rated breaking capacity Icu: 4.5 kA
Rated current In: 16 A
Durability mech./el.: ≤10 000 / ≤4 000 cycles
Operating temperature range: –25…+40 °C
Rated making and breaking capacity: 500 A
Mounting: on DIN-rail 35 mm
Characteristics: electronic
Operating position: vertical/horizontal (deviation ≤5°)
Weight: ≤170 g
Type: AC
Warranty: 12 months
Article: s034006
Connection to FORK type busbar: no
Current limitation class: 2
Differential tripping current: 10 mA
Number of poles: 2
Impulse withstand voltage Uimp: 6 kV
Terminal torque: 3.5 Nm
Altitude above sea level: 2000 m
Insulation voltage Ui: 500 V
Rated operating voltage Ue: AC 230 V
Rated frequency: 50 Hz
Climatic performance: UHL4
Max. cross-section of the connected wires: 25 mm²
Protection degree: IP20
Compliance with standards: DSTU EN 61008-1
Disposal method: transfer to a specialized company
Rated breaking capacity Icu: 4.5 kA
Rated current In: 16 A
Durability mech./el.: ≤10 000 / ≤4 000 cycles
Operating temperature range: –25…+40 °C
Rated making and breaking capacity: 500 A
Mounting: on DIN-rail 35 mm
Characteristics: electronic
Operating position: vertical/horizontal (deviation ≤5°)
Weight: ≤170 g
Type: AC
Warranty: 12 months
-
Number of poles:2P
-
Rated current [A]:16 A
-
Maximum leakage current [mA]:10 mA
-
Type:Type AC
-
Short circuit and overload protection:without fuse
